Representation Training (Stage 1)

SPATIA offers two gene encoder backends. SPATIA-scprint (primary, scPRINT-based) uses a Flash Transformer with ViT-MAE image cross-attention. SPATIA-scgpt (alternative) uses a scGPT-style transformer with mixture-of-experts layers.

Prerequisites

Before training, you need:

MIST dataset — constructed via the Dataset Construction pipeline (lamindb Collection + LMDB)

Base scPRINT checkpoint — download with:

cd gene_encoders/SPATIA-scprint/data/model && bash download.sh

Gene embeddings — data/generated/gene_embeddings.parquet (from the scPRINT pretrained model)
Biomart gene positions — data/main/biomart_pos.parquet (shipped in this repo)

SPATIA-scprint (Primary)

Configure paths

Edit gene_encoders/SPATIA-scprint/config/0510_base_spatial_all_crossattention_medium.yml:

data:
  spatial_datadir: /your/path/to/lmdb/all.lmdb     # LMDB from Stage C
  collection_name: xenium_all_0212                   # lamindb Collection from Stage B
  gene_embeddings: ./data/generated/gene_embeddings.parquet
  do_gene_pos: ./data/main/biomart_pos.parquet
model:
  ckpt_path: ./data/model/scPRINT/medium.ckpt       # base scPRINT checkpoint
  clip_model_type: "facebook/vit-mae-base"           # ViT-MAE image encoder

Run training

cd gene_encoders/SPATIA-scprint

scprint_spatial fit \
    --config config/0510_base_spatial_all_crossattention_medium.yml \
    --model.ckpt_path data/model/scPRINT/medium.ckpt \
    --data.batch_size 8

Training uses PyTorch Lightning with bf16 mixed precision, DDP strategy, and Weights & Biases logging.

Extract embeddings (SPATIA-scprint)

python prediction_tasks/scripts/extract_spatia_embeddings.py \
    --checkpoint /path/to/scprint_checkpoint.ckpt \
    --adata_path /path/to/dataset.h5ad \
    --lmdb_dir /path/to/images.lmdb \          # omit for gene-only mode
    --output_path embeddings/spatia_embeddings.npy

SPATIA-scgpt (Alternative)

Run training

cd gene_encoders/SPATIA-scgpt
bash scgpt_spatial/0704_train_spatial_4h100.sh

Extract embeddings (SPATIA-scgpt)

python gene_encoders/SPATIA-scgpt/tutorials/extract_multimodal_embeddings.py \
    --spatial-config-path /path/to/config.json \
    --spatial-weight-path /path/to/best_model.pt \
    --h5ad-file /path/to/dataset.h5ad \
    --spatial-datadir /path/to/images.lmdb \
    --output-path /path/to/output

Architecture Summary

Component	Detail
Gene encoder	Flash Transformer, d_model 256, 8 layers
Image encoder	ViT-MAE base (12 enc / 8 dec layers, patch 16)
Fusion	Cross-attention (image queries, gene keys/values)
Image init	`facebook/vit-mae-base` (ImageNet-1k)
Gene init	scPRINT pretrained (mandatory)
Total params	~155M
Training precision	bf16-mixed
